XiCA Spec
XiCA sublimates the stability of heating films to global standards.
XiCA Specification and standard for heating film
Click the product name to see the image.
Image | Classifcation | Characteristic | Power Consumption [W/㎡] |
heating Temperature [℃] |
Thickness [mm] |
width [mm] |
Packing Length [m/Box] |
Weight [kg] |
Color |
standard | For general heating | 230[W/㎡] | 40~45[℃] | 0.338 | 500 | 150 | 37 | Transparency. Translucent | |
800 | 100 | 40 | |||||||
1000 | 100 | 48 | |||||||
self-80 | Temperature control within 80 degrees in case of local overheating | 230[W/㎡] | 40~45[℃] | 0.338 | 500 | 150 | 37 | Red (color can be changed in OEM production) |
|
Ultra | Full coating type | 230[W/㎡] | 40~45[℃] | 0.5 | 500 | 150 | 37 | Translucent | |
800 | 100 | 40 | |||||||
1000 | 100 | 48 | |||||||
Ultra-PTC | Installed in humid areas to reduce local overheating | 230[W/㎡] | 40~45[℃] | 0.5 | 500 | 150 | 37 | White, logo type (can be changed) | |
800 | 100 | 40 | |||||||
1000 | 100 | 40 | |||||||
PTC | Heating products to reduce the risk of local overheating | 230[W/㎡] | 40~45[℃] | 0.338 | 500 | 150 | 37 | Red (color can be changed in OEM production) |
|
800 | 100 | 40 | |||||||
1000 | 100 | 40 |
